Mechanical Ventilation for Severe Asthma

Mechanical Ventilation

“Wheezing” is a prominent complaint in the Ped ED and it has been a frequent topic of the PedEM Morsels.  We have covered a wide variety of Asthma management aspects: from initial therapies (MDIs vs Nebs) to potential hydration issues; from the utility of Magnesium to the Heliox. We have also discussed more advanced topics like Noninvasive Ventilation and how to Avoid Oxygen Desats as well as Delayed Sequence Intubation.  While the goal is often to prevent intubation, occasionally, the only option is to use Mechanical Ventilation for your patient with Severe Asthma.  The question, then, is how to make the best of a bad situation.

Important Pathophysiology

  • There are several significant alterations that occur with acute, severe asthma exacerbations (Oddo, 2006).
    • Heterogenous and reversible increased airway resistance
    • Severe limitation of expiratory flow
    • Premature airway closure
    • Lung hyperinflation
      • Decreased elastic recoil and increased FRC of up to 2 times normal and decreased
    • Chest wall dynamic changes
    • High intrinsic PEEP
  • These produce clinically apparent:
    • Respiratory fatigue
      • Increased utilization of accessory muscles of respiration
    • Ventilation/Perfusion Mismatch
      • Very heterogenous areas of lung parenchyma with varying degrees of aeration
    • Barotrauma
      • High pulmonary pressures
    • Hemodynamic instability
      • Increased intrathoracic pressures negatively influencing the cardiac venous return/Preload and, hence, cardiac output.



The Bad Situation: Needing to Intubate

  • Fortunately, most often the patient with severe Status Asthmaticus can be managed without intubating.
    • Recent population study found incidence of intubation for status asthmaticus was 0.55% (Sankeerth, 2014)
    • Unfortunately, mechanical ventilation is associated with higher mortality.
  • Indications for using Mechanical Ventilation for the patient with severe status asthmatics:
    • This is a Clinical Decision!
      • There is no lab value will define a need to intubate.
      • Progressive exhaustion/fatigue with Altered Mental Status are the primary reasons.
      • A cooperative patient, even if hypercapnic, may be managed with maximizing other therapies (see Noninvasive Ventilation and Magnesium).
      • Hypoxia is usually not the sole reason to intubate, as supplemental oxygen typically corrects this; however, severe VQ mismatch can occur and be problematic.  May require advanced techniques (see Delayed Sequence Intubation).
    • There is a portion of patient who will present with Acute Asphyxial Asthma (Maffei 2004).
      • These patients deteriorate rapidly and often require intubation upon arrival in the ED or within the first 30 minutes of management.
      • Interestingly, these children have shorter durations of mechanical ventilation.
    • Where you work plays a role (Shibata, 2014).
      • Transport from a community ED to a tertiary center may be more problematic if the child is already tenuous.



The Problem with Mechanical Ventilation

  • Intubating a child should never be considered cavalierly, but after successfully placing the ETT, the real tricky part begins: not causing more harm with the mechanical ventilation process.
  • Already the patient has severe hyperinflation, poor respiratory mechanics, and potential restricted preload.
  • Complications of mechanical ventilation
    • Hemodynamic instability following intubation.
      • Hypotension occurs as a result of worsening hyperinflation leading to decreased cardiac preload.
      • Cardiac Arrest can occur due to this progression as well.
    • Barotrauma
    • Pneumothorax
    • Ventilator Associated Pneumonia
      • Most common – accounting for ~10% of the complications (Sankeerth, 2014)



Making the Best of a Bad Situation

  • If you have been placed between the rock and the hard place, and now must use mechanical ventilation, consider the following:
    • Use a Cuffed Endotracheal Tube!
    • Initial Ventilator Settings (Oddo, 2006):
      • Mode: there is no evidence to support one mode over another. Many start with Volume-Control.
      • Tidal Volume: 6-10 ml/kg ideal body weight
        • Enough to move the chest.
      • Expiratory Time: 4-5 seconds
        • Inspiratory:Expiratory ratio may be 1:4, but can be as high as 1:8
        • Goal is to allow exhalation and avoid stacking breaths with barotrauma.
      • Resp Rate: Below physiologic rate for age.
        • Controlled Hypoventilation has been shown to be safe (Dworkin, 1989)
      • PEEP: zero (in acute phase. PEEP used once improving and weaning starts).
      • FiO2: can start at 100%, but titrate to keep sats >90%.
    • Keep the child adequately sedated!
      • Avoid patient-ventilator asynchrony.
      • Also helps decrease CO2 production.
      • Ketamine is a useful med to consider!
      • It is best to avoid prolonged neuromuscular paralysis if you are able to.
    • Keep Plateau Pressures <30 cmH20
      • Increased risk of barotrauma above this level.
      • Measured by an end-inspiratory pause of several seconds in a system without leaks (hence, the cuffed ETT).



The Bad Situation Just Got Worse

  • If, after initiation of mechanical ventilation, the patient become hemodynamically compromised:
  • Step 1 – Disconnect from the Ventilator and allow the chest to recoil.
    • If the hemodynamics improve, restart the mechanical ventilation at a lower tidal volume and respiratory rate.
    • If the hemodynamics don’t improve… move to step 2.
  • Step 2 – After you cry on the inside, consider typical complications.
    • Dislodged ETT tube
      • Using continuous End-Tidal CO2 Monitoring helps here!!
      • Videoscopic Laryngoscope and or Ultrasound can help reconfirm as well.
    • Obstructed ETT tube
      • Suction the tube
    • Pneumothorax
      • Bedside Ultrasound is going to be faster and more sensitive than the portable CXR.
    • Equipment Failure
      • Because some days are just that kind of day.



References

Wade A1, Chang C. Evaluation and Treatment of Critical Asthma Syndrome in Children. Clin Rev Allergy Immunol. 2014 Feb 1. PMID: 24488329. [PubMed] [Read by QxMD]

Rampa S1, Allareddy V, Asad R, Nalliah RP, Allareddy V, Rotta AT. Outcomes of invasive mechanical ventilation in children and adolescents hospitalized due to status asthmaticus in United States: a population based study. J Asthma. 2014 Oct 14:1-8. PMID: 25295383. [PubMed] [Read by QxMD]

Shibata S1, Khemani RG, Markovitz B. Patient origin is associated with duration of endotracheal intubation and PICU length of stay for children with status asthmaticus. J Intensive Care Med. 2014 May-Jun;29(3):154-9. PMID: 23753230. [PubMed] [Read by QxMD]

Nievas IF1, Anand KJ. Severe acute asthma exacerbation in children: a stepwise approach for escalating therapy in a pediatric intensive care unit. J Pediatr Pharmacol Ther. 2013 Apr;18(2):88-104. PMID: 23798903. [PubMed] [Read by QxMD]

Rubin BK1, Pohanka V. Beyond the guidelines: fatal and near-fatal asthma. Paediatr Respir Rev. 2012 Jun;13(2):106-11. PMID: 22475257. [PubMed] [Read by QxMD]

Oddo M1, Feihl F, Schaller MD, Perret C. Management of mechanical ventilation in acute severe asthma: practical aspects. Intensive Care Med. 2006 Apr;32(4):501-10. PMID: 16552615. [PubMed] [Read by QxMD]

Maffei FA1, van der Jagt EW, Powers KS, Standage SW, Connolly HV, Harmon WG, Sullivan JS, Rubenstein JS. Duration of mechanical ventilation in life-threatening pediatric asthma: description of an acute asphyxial subgroup. Pediatrics. 2004 Sep;114(3):762-7. PMID: 15342851. [PubMed] [Read by QxMD]

Dworkin G1, Kattan M. Mechanical ventilation for status asthmaticus in children. J Pediatr. 1989 Apr;114(4 Pt 1):545-9. PMID: 2494314. [PubMed] [Read by QxMD]
